Solar Panel Jinko 72HL4 555-575Watts
|
| Warranty |
|
| Product Warranty |
12 Years |
| Power Warranty |
30 Years of 87.4% Output Power |
| Electrical Data at STC |
|
| Maximum Power (Pmax) |
| 555 Wp |
560 Wp |
565 Wp |
570 Wp |
575 Wp |
|
| Voltage at Maximum Power (Vmpp) |
| 41.64 V |
41.77 V |
41.92 V |
42.07 V |
42.22 V |
|
| Current at Maximum Power (Impp) |
| 13.33 A |
13.41 A |
13.48 A |
13.55 A |
13.62 A |
|
| Open Circuit Voltage (Voc) |
| 50.34 V |
50.47 V |
50.6 V |
50.74 V |
50.88 V |
|
| Short Circuit Current (Isc) |
| 14.07 A |
14.15 A |
14.23 A |
14.31 A |
14.39 A |
|
| Panel Efficiency |
| 21.48 % |
21.68 % |
21.87 % |
22.07 % |
22.26 % |
|
| Power Tolerance (Positive) |
| + 3 % |
+ 3 % |
+ 3 % |
+ 3 % |
+ 3 % |
|
|
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C |
| Electrical Data at NOCT |
|
| Maximum Power (Pmax) |
| 417 Wp |
421 Wp |
425 Wp |
429 Wp |
432 Wp |
|
| Voltage at Maximum Power (Vmpp) |
| 39.12 V |
39.25 V |
39.38 V |
39.51 V |
39.6 V |
|
| Current at Maximum Power (Impp) |
| 10.67 A |
10.73 A |
10.79 A |
10.85 A |
10.92 A |
|
| Open Circuit Voltage (Voc) |
| 47.82 V |
47.94 V |
48.06 V |
48.2 V |
48.33 V |
|
| Short Circuit Current (Isc) |
| 11.36 A |
11.42 A |
11.49 A |
11.55 A |
11.62 A |
|
| Temperature |
45±2 °C |
|
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C |
| Thermal Ratings |
|
| Operating Temperature Range |
-40~85 °C |
| Temperature Coefficient of Pmax |
-0.3 %/°C |
| Temperature Coefficient of Voc |
-0.25 %/°C |
| Temperature Coefficient of Isc |
0.046 %/°C |
| Maximum Ratings |
|
| Maximum System Voltage |
1500 V |
| Series Fuse Rating |
25 A |
| Material Data |
|
| Panel Dimension (H/W/D) |
2278x1134x35 mm |
| Weight |
28 kg |
| Cell Type |
Monocrystalline |
| Cell Number |
144 |
| Glass Type |
Anti-reflection Coating, Tempered |
| Glass Thickness |
3.2 mm |
| Frame Type |
Anodized Aluminium |
| Junction Box Protection Class |
IP 68 |
| Cable Crossection |
4 mm2 |
